FDLP 鎢鋼平底鑽頭
| 型號 MODEL |
外徑 (D) |
刃長 (FL) |
有效長 (NL) |
刃數 (F) |
柄徑 (d) |
全長 (AL) |
|---|---|---|---|---|---|---|
| FDLP010 | 1 | 3.3 | 3.6 | 2 | 3 | 50 |
| FDLP011 | 1.1 | 3.5 | 3.9 | 2 | 3 | 50 |
| FDLP012 | 1.2 | 3.9 | 4.2 | 2 | 3 | 50 |
| FDLP013 | 1.3 | 4.2 | 4.5 | 2 | 3 | 50 |
| FDLP014 | 1.4 | 4.6 | 4.9 | 2 | 3 | 50 |
| FDLP015 | 1.5 | 4.9 | 5.2 | 2 | 3 | 50 |
| FDLP016 | 1.6 | 5.2 | 5.5 | 2 | 3 | 50 |
| FDLP017 | 1.7 | 5.5 | 5.8 | 2 | 3 | 50 |
| FDLP018 | 1.8 | 5.8 | 6.1 | 2 | 3 | 50 |
| FDLP019 | 1.9 | 6.2 | 6.5 | 2 | 3 | 50 |
| FDLP020 | 2 | 9 | 9.8 | 2 | 4 | 50 |
| FDLP021 | 2.1 | 11 | 11.4 | 2 | 4 | 50 |
| FDLP022 | 2.2 | 11 | 11.4 | 2 | 4 | 50 |
| FDLP023 | 2.3 | 11 | 11.5 | 2 | 4 | 50 |
| FDLP024 | 2.4 | 12 | 12.6 | 2 | 4 | 50 |
| FDLP025 | 2.5 | 12 | 12.7 | 2 | 4 | 50 |
| FDLP026 | 2.6 | 12 | 12.8 | 2 | 4 | 50 |
| FDLP027 | 2.7 | 14 | 14.9 | 2 | 4 | 50 |
| FDLP028 | 2.8 | 14 | 15 | 2 | 4 | 50 |
| FDLP029 | 2.9 | 14 | 15 | 2 | 4 | 50 |
| FDLP030 | 3 | 14 | 14.4 | 2 | 6 | 60 |
| FDLP031 | 3.1 | 15 | 15.5 | 2 | 6 | 60 |
| FDLP032 | 3.2 | 15 | 15.6 | 2 | 6 | 60 |
| FDLP033 | 3.3 | 15 | 15.7 | 2 | 6 | 60 |
| FDLP034 | 3.4 | 16 | 16.2 | 2 | 6 | 60 |
| FDLP035 | 3.5 | 16 | 16.3 | 2 | 6 | 60 |
| FDLP036 | 3.6 | 16 | 16.4 | 2 | 6 | 60 |
| FDLP037 | 3.7 | 18 | 18 | 2 | 6 | 60 |
| FDLP038 | 3.8 | 18 | 18.1 | 2 | 6 | 60 |
| FDLP039 | 3.9 | 18 | 18.2 | 2 | 6 | 60 |
| FDLPO40 | 4 | 18 | 18.3 | 2 | 6 | 60 |
| FDLPO41 | 4.1 | 19 | 20.4 | 2 | 6 | 60 |
| FDLPO42 | 4.2 | 19 | 20.4 | 2 | 6 | 60 |
| FDLPO43 | 4.3 | 19 | 20.5 | 2 | 6 | 60 |
| FDLPO44 | 4.4 | 21 | 22.6 | 2 | 6 | 60 |
| FDLPO45 | 4.5 | 21 | 22.7 | 2 | 6 | 60 |
| FDLPO46 | 4.6 | 21 | 22.8 | 2 | 6 | 60 |
| FDLPO47 | 4.7 | 22 | 22.9 | 2 | 6 | 60 |
| FDLPO48 | 4.8 | 22 | 23 | 2 | 6 | 60 |
| FDLPO49 | 4.9 | 22 | 23 | 2 | 6 | 60 |
| FDLP050 | 5 | 23 | 23.1 | 2 | 6 | 75 |
| FDLP051 | 5.1 | 24 | 26.2 | 2 | 6 | 75 |
| FDLP052 | 5.2 | 24 | 26.3 | 2 | 6 | 75 |
| FDLP053 | 5.3 | 24 | 26.4 | 2 | 6 | 75 |
| FDLP054 | 5.4 | 25 | 27.5 | 2 | 6 | 75 |
| FDLP055 | 5.5 | 25 | 27.6 | 2 | 6 | 75 |
| FDLP056 | 5.6 | 25 | 27.7 | 2 | 6 | 75 |
| FDLP057 | 5.7 | 27 | 29.7 | 2 | 6 | 75 |
| FDLP058 | 5.8 | 27 | 29.8 | 2 | 6 | 75 |
| FDLP059 | 5.9 | 27 | 29.9 | 2 | 6 | 75 |
| FDLP060 | 6 | 27 | 30 | 2 | 6 | 75 |
| FDLP061 | 6.1 | 28 | 31 | 2 | 8 | 75 |
| FDLP062 | 6.2 | 28 | 31 | 2 | 8 | 75 |
| FDLP063 | 6.3 | 28 | 31 | 2 | 8 | 75 |
| FDLP064 | 6.4 | 30 | 33 | 2 | 8 | 75 |
| FDLP065 | 6.5 | 30 | 33 | 2 | 8 | 75 |
| FDLP066 | 6.6 | 30 | 33 | 2 | 8 | 75 |
| FDLP067 | 6.7 | 31 | 33 | 2 | 8 | 75 |
| FDLP068 | 6.8 | 31 | 33 | 2 | 8 | 75 |
| FDLP069 | 6.9 | 31 | 33 | 2 | 8 | 75 |
| FDLP070 | 7 | 32 | 33 | 2 | 8 | 75 |
| FDLP071 | 7.1 | 33 | 36 | 2 | 8 | 75 |
| FDLP072 | 7.2 | 33 | 36 | 2 | 8 | 75 |
| FDLP073 | 7.3 | 33 | 36 | 2 | 8 | 75 |
| FDLP074 | 7.4 | 34 | 39 | 2 | 8 | 75 |
| FDLP075 | 7.5 | 34 | 39 | 2 | 8 | 75 |
| FDLP076 | 7.6 | 34 | 39 | 2 | 8 | 75 |
| FDLP077 | 7.7 | 36 | 39 | 2 | 8 | 75 |
| FDLP078 | 7.8 | 36 | 40 | 2 | 8 | 80 |
| FDLP079 | 7.9 | 36 | 40 | 2 | 8 | 80 |
| FDLP080 | 8 | 36 | 40 | 2 | 8 | 80 |
| FDLP081 | 8.1 | 37 | 42 | 2 | 10 | 100 |
| FDLP082 | 8.2 | 37 | 42 | 2 | 10 | 100 |
| FDLP083 | 8.3 | 37 | 42 | 2 | 10 | 100 |
| FDLP084 | 8.4 | 39 | 42 | 2 | 10 | 100 |
| FDLP085 | 8.5 | 39 | 42 | 2 | 10 | 100 |
| FDLP086 | 8.6 | 39 | 42 | 2 | 10 | 100 |
| FDLP087 | 8.7 | 40 | 42 | 2 | 10 | 100 |
| FDLP088 | 8.8 | 40 | 42 | 2 | 10 | 100 |
| FDLP089 | 8.9 | 40 | 42 | 2 | 10 | 100 |
| FDLP090 | 9 | 41 | 42 | 2 | 10 | 100 |
| FDLP091 | 9.1 | 42 | 45 | 2 | 10 | 100 |
| FDLP092 | 9.2 | 42 | 45 | 2 | 10 | 100 |
| FDLP093 | 9.3 | 42 | 45 | 2 | 10 | 100 |
| FDLP094 | 9.4 | 43 | 45 | 2 | 10 | 100 |
| FDLP095 | 9.5 | 43 | 45 | 2 | 10 | 100 |
| FDLP096 | 9.6 | 43 | 45 | 2 | 10 | 100 |
| FDLP097 | 9.7 | 45 | 48 | 2 | 10 | 100 |
| FDLP098 | 9.8 | 45 | 48 | 2 | 10 | 100 |
| FDLP099 | 9.9 | 45 | 48 | 2 | 10 | 100 |
| FDLP100 | 10 | 45 | 48 | 2 | 10 | 100 |
| FDLP101 | 10.1 | 46 | 49 | 2 | 12 | 100 |
| FDLP102 | 10.2 | 46 | 49 | 2 | 12 | 100 |
| FDLP103 | 10.3 | 46 | 49 | 2 | 12 | 100 |
| FDLP104 | 10.4 | 48 | 51 | 2 | 12 | 100 |
| FDLP105 | 10.5 | 48 | 51 | 2 | 12 | 100 |
| FDLP106 | 10.6 | 48 | 51 | 2 | 12 | 100 |
| FDLP107 | 10.7 | 49 | 51 | 2 | 12 | 100 |
| FDLP108 | 10.8 | 49 | 51 | 2 | 12 | 100 |
| FDLP109 | 10.9 | 49 | 51 | 2 | 12 | 100 |
| FDLP110 | 11 | 50 | 51 | 2 | 12 | 100 |
| FDLP111 | 11.1 | 51 | 54 | 2 | 12 | 100 |
| FDLP112 | 11.2 | 51 | 54 | 2 | 12 | 100 |
| FDLP113 | 11.3 | 51 | 54 | 2 | 12 | 100 |
| FDLP114 | 11.4 | 52 | 54 | 2 | 12 | 100 |
| FDLP115 | 11.5 | 52 | 54 | 2 | 12 | 100 |
| FDLP116 | 11.6 | 52 | 54 | 2 | 12 | 100 |
| FDLP117 | 11.7 | 54 | 57 | 2 | 12 | 100 |
| FDLP118 | 11.8 | 54 | 57 | 2 | 12 | 100 |
| FDLP119 | 11.9 | 54 | 57 | 2 | 12 | 100 |
| FDLP120 | 12 | 54 | 57 | 2 | 12 | 100 |
| FDLP125 | 12.5 | 57 | 60 | 2 | 12 | 125 |
| FDLP130 | 13 | 59 | 60 | 2 | 12 | 125 |
| FDLP135 | 13.5 | 61 | 63 | 2 | 12 | 125 |
| FDLP140 | 14 | 63 | 66 | 2 | 12 | 125 |
| FDLP145 | 14.5 | 66 | 69 | 2 | 12 | 125 |
| FDLP150 | 15 | 68 | 69 | 2 | 12 | 125 |
| FDLP155 | 15.5 | 70 | 72 | 2 | 12 | 125 |
| FDLP160 | 16 | 72 | 75 | 2 | 16 | 125 |
| FDLP165 | 16.5 | 75 | 78 | 2 | 16 | 125 |
| FDLP170 | 17 | 77 | 79 | 2 | 16 | 150 |
| FDLP175 | 17.5 | 79 | 81 | 2 | 16 | 150 |
| FDLP180 | 18 | 81 | 84 | 2 | 16 | 150 |
| FDLP185 | 18.5 | 84 | 87 | 2 | 16 | 150 |
| FDLP190 | 19 | 86 | 87 | 2 | 16 | 150 |
| FDLP195 | 19.5 | 88 | 91 | 2 | 16 | 150 |
| FDLP200 | 20 | 90 | 93 | 2 | 20 | 150 |
